3 In 1 NC Servo Roll Feeder Peripheral Automation Equipment Plastic Sheet Processing

3 In 1 NC Servo Roll Feeder Peripheral Automation Equipment Plastic Sheet Processing

As a new type of peripheral automation equipment with high efficiency, energy saving and land saving, the 3-in-1 feeder is more and more widely used in stamping production.

Although the 3-in-1 feeder has various styles, types and appearances, the main structure is composed of two major functional components: the rack part and the leveling feeding part. The leveling feeding part includes the front feeding device and the middle leveling. Device, rear feeding device, etc.

Ruihui made a structural improvement corresponding to the above-mentioned shortcomings of the existing 3-in-1 feeder. The roller cylinder before the feeding of the 3-in-1 feeder was changed from automatic valve control to manual valve control. The manual valve was installed on the manual valve. The manual valve control box of the feeder frame.

When the front roller cylinder is in use, it is only used during the material feeding process to facilitate the dragging of the material into the middle leveling device. When the automatic feeding is performed, the front relaxation roller is directly lifted without any action, which is convenient for the user to operate and ensure.

The 3-in-1 feeder is relaxed and accurate.

At the same time, the 3-in-1 feeder guide shaft is designed between the two side plates, wherein the guide shafts are provided with threads at both ends, and the sides of each side plate are respectively fixed by the nut and the guide shaft. The nut is also provided with a radial threaded through hole and a connecting screw.

It avoids the failure of the relevant parts loosening due to the vibration of the punching machine during the use of the 3-in-1 feeder. At the same time, the positive guide shaft of the side plate can be effectively guided, and the positive guide shaft can be adjusted to eliminate the error in case of error. The feeding accuracy of the 3-in-1 feeder is guaranteed.

products:

specifications

FAQ:

Q1:What kinds of machines do you have?
Our main products are:Nc Servo Roll Feeder,Uncoiler, Straightener, 3 in1 Straightener Feeder,Transfer systems,Press Feeding Line., etc
Q2:Is your equipment standard or customized?
Both, we can OEM & ODM with customers.
Q3:What are your equipments certification?
All our items are coming with CE certifications.
Q4:How did your company's quality system work?
"QUALITY IS OUR CULTURE" Our quality is not the best in the world, and the price is not the cheapest. But we can provide you excellent products to defeat your competitors.
Q5:How long is the warranty period of the machine?
We offer free service with a warranty period of one year, If it is operate in reasonable, the machine can be used more than 10 years.
Q6: Is it possible to be a foreign agent and distributor?
If you are confidence and excellent service for after-sales, then welcome to be our agents or distributors all over the world.
Q7:What's your payment?
T/T,D/P,L/C,Western Union., etc
Q8:What's the delivery?
"TIME IS GOLD" for you and for us, so we have professional team work and production line can make nice quality in short time.

servo feeder machine

sheet feeder machine

3 In 1 NC Servo Roll Feeder Peripheral Automation Equipment Plastic Sheet Processing Images
